Feature:

1. Plug and Play: Standard USB power supply interface, easy to operate, users support key switch LiPO (3.7/4.20V) /Li‑Hv (3.8/4.35V).
2. Intelligent Battery Type Setting Instructions: LiPO LED slow flash charging process, Li‑Hv LED flash charging process.
3. Smart Access to Check Battery: No battery access, LED indicates the battery setting type, from right to left is LiPO, and from left to right is Li‑Hv.
4. Indicate Charging Status: 4 LED lights independently indicate the charging status of the four channels, the charging process is intermittent, and the charging is complete.
5. Simultaneous Charging: Four independent charging output channels can charge four batteries at the same time. It also supports LiPO lithium battery and Li‑Hv high voltage lithium battery.

Specification:

Item Type: CX405 4CH USB Battery Charger
Color: As Picture Shown
Weight: Approx.15g/0.5oz
Material: Plastic + Electronic Components
Support Battery Part: 1 Mobile Phone
Usb Interface Power Supply Input Range: 5V±5% 0.5~2A
Support Battery Interface: Mcpx, for , JST (differentiated Models)
Battery Charging Interface Output Voltage Range: 2.50~4.35V Lipo Cell 1 or Li-Hv
Battery Charging Interface Current Output Range: 500mA X 4CH USB 5V/2A
Battery Charge Termination Voltage: Lipo Type 4.20V±5%, Lithium Type HV 4.35V±5%
Battery Charging Interface Output Power Range: 2.1W X 4CH USB 5V/2A
Display Mode: 4 Green LED Indicators Three State Display Independent Light (no Battery, Charging, Full)
